Volume: 9, Issue: 2, February, 2019
DOI: 10.7324/JAPS.2019.90214

Research Article

Evaluation of Cissus populnea gum as a directly compressible matrix system for tramadol hydrochloride extended-release tablet

Olutayo Ademola Adeleye1, Mbang N. Femi-Oyewo1, Michael A. Odeniyi2, Tolulope O. Ajala2

  Author Affiliations


The aim of this study was to evaluate and compare the compactibility, mechanical and release properties of tramadol tablets prepared by direct compression using cissus gum, a naturally occurring plant polymer as directly compressible excipient in comparison with xanthan gum. Compactibility was measured by Heckle, mechanical properties by tensile strength and friability, and release properties by dissolution profile. Student t-test with GraphPad Prism 5 was used to identify differences between data at p < 0.05. The result showed that the Py of xanthan formulation was significantly lower than cissus formulations (p = 0.03). Onset of plastic deformation was directly dependent on the concentration of the polymer and the properties of the active ingredient. The presence of the active ingredient retarded the onset of plastic deformation. There was increase in crushing strength and tensile strength with decrease in friability as the concentration of the polymer increased in all formulations. The mechanical properties of cissus gum and xanthan gum formulations were not significantly different (p > 0.05). Tramadol dissolution decreased as the concentration of the polymers increased. Cissus gum has some properties that would make it suitable as direct compressible excipient in matrix systems for extended-release.


Tramadol hydrochloride tablet, cissus gum, xanthan gum, direct compression, compaction.

Citation: Adeleye OA, Femi-Oyewo MN, Odeniyi MA, Ajala TO. Evaluation of Cissus populnea gum as a directly compressible matrix system for tramadol hydrochloride extended-release tablet. J Appl Pharm Sci, 2019; 9(02):105–111.

Copyright: The Author(s). This is an open access article distributed under the Creative Commons Attribution Non-Commercial License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.


Abioye AO, Odusote MO Ifudu ND, Silva BO. In vitro release kinetics of salicylic acid from Cissus populnea gel. J Pharm Sci and Pharm Prac, 2001; 7: 113-118.

Abioye AO, Odusote MO, Ifudu ND, Silva BO. A physicochemical basis for the stability effect of Cissuspopulnea gum in Oil-in-Water extemporaneous emulsions. J Pharm Sci and Pharm Prac, 2000; 6: 17-22.

Adeleye AO, Femi-Oyewo MN, Odeniyi MA. The effect of processing variables on the mechanical and release properties of tramadol matrix Tablets incorporating Cissuspopulneagum as controlled release excipient. Polim Med, 2014;44: 209-220.

Adeleye AO, Femi-Oyewo MN, Odeniyi MA. Effect of compression pressure on mechanical and release properties of tramadol matrix tablets Curr Issues Pharm Med Sci, 2015; 28: 120-125.

Adeleye AO, Femi-Oyewo MN, Odeniyi MA. Physicochemical and rheological characterization ofCissuspopulneagum extracted by different solvents West Afr J Pharm, 2015;26: 113-126.

Adeleye AO, Odeniyi MA, Jaiyeoba KT. The influence of cissus gum on the mechanical and release properties of paracetamol tablets – a factorial analysis. J Basic and Appl Pharm Sci, 2010;31: 131-142

Adeleye AO, Odeniyi MA, Jaiyeoba KT. (2011). Evaluation of cissus gum as binder in a paracetamol tablet formulation. Farmacia 59: 85-96.

Adetunji OA, Odeniyi MA, Itiola OA. Compression, mechanical and release properties of chloroquine phosphate tablets containing corn and trifoliate yam starches as binders. Trop J Pharm Res, 2006; 5: 589-596.

AnroopB, Navpreet, MM, Ashok K, Lalit K. Studies on Ocimumgratissimumseed mucilage: Evaluation of suspending properties. Indian J Pharm Sci, 2005; 67: 206-209.

Bharadia PD,Patel GC, Patel, M M. A preliminary investigation on sesbania gum as a pharmaceutical excipient. Int J Pharm Excipients, 2004;1: 102-105

Carr R. (1965). Evaluating flow property of solids. ChemEng, 1965;72: 163–8.

Eichie FE, Amalime AE. Evaluation of the binder effects of the gum mucilages of Cissuspopulnea and Acassia Senegal on the mechanical properties of paracetamol tablets. Afr J Biotech, 2007; 6: 2208-2211https://doi. org/10. 5897/AJB2007. 000-2345

Emeje M, Nwabunike P, Isimi C, Fortunak J, Mitchell JW, ByrnS, Kunle O, Ofoefule S. Isolation, characterization and formulation properties of a new plant gum obtained from Cissusrefescence. Afr J Pharm Pharmacol, 2009; 3: 16-23.

Fell JT, Newton JM. Determination of tablet strength by the diametral-compression test. J Pharm Sci, 1970; 59: 688-691. https://doi. org/10. 1002/jps. 2600590523

Femi-Oyewo MN, Spring MS. Granulation with surfactants: The effect of affinityof the substrate for water on the properties of the resulting granules and compacts. Nig J Pharm Sci, 1986; 2: 52-60.

Gade R, Murthy T. Effect of hydrophilic and hydrophobic polymers on release kinetics of metoprolol succinate extended release tablets. Asian J Pharm, 2011; 5: 101-6. https://doi. org/10. 4103/0973-8398. 84550

Genc L, Bilac H, Guler E. Studies on controlled release dimenhydrinate from matrix tablet formulations. Pharm ActaHelv, 1999;74: 43-49. https://doi. org/10. 1016/S0031-6865(99)00017-5

Giorgio P, Patrizia R. The safety of pharmaceutical excipients. Farmaco, 2003; 58: 541-550. https://doi. org/10. 1016/S0014-827X(03)00079-X

Grond S, Sablotzki A. Clinical pharmacology of tramadol. Clinpharmacokinet, 2004; 43: 879-923. https://doi. org/10. 2165/00003088-200443130-00004

Hausner HH. Friction conditions in a mass of metal powders. Int J Powder Metall, 1967; 3: 7-13.

Hiestand EN, Well JE, Peot CB, Ocha JF. Physical processing of tableting. J Pharm Sci, 1977; 66: 510-519. https://doi. org/10. 1002/jps. 2600660413

Ibrahim H,Rai PP, Bangudu AB. Evaluation of mucilage from the stem bark of Cissuspopulnea. Afr J Pharm. Sci, 1999; 22: 35-41.

Ibrahim MA, Dawes VH, Bangudu AB. Evaluation of Cissuspopulnea polymer as a matrix former for controlled drug release. J PhytomedTher, 2002; 5: 23-32.

Itiola OA and Pilpel N. Formulation effects on the mechanical properties of metronidazole tablets. J Pharm Pharmacol, 1991; 43: 145-147. https://doi. org/10. 1111/j. 2042-7158. 1991. tb06655. x

Itiola OA, Pilpel N. Tableting characteristics of metronidazole formulations. Int J Pharm, 1986; 31: 99-105. https://doi. org/10. 1016/0378-5173(86)90218-8

Jan SU, Khan GM, Hussain I. Formulation development and investigation of ibuprofen controlled release tablets with hydrophilic polymers and the effect of coexcipients on drug release patterns. Pakistan J PharmaSci, 2012; 25: 751-6

Khan GM, Jiabi Z. Formulation and in-vitro evaluation of ibuprofen-carbopol 974 PNF controlled release matrix tablets III: Influence of co-excipients on release rate of the drug. J. Controlled Release, 1998;54: 185-190. https://doi. org/10. 1016/S0168-3659(97)00225-3

Kulkarni GT, Ambike SH, Ramsay MP. Evaluation of binding properties of Plantagoovata and Trigonellafoenumgraecum mucilage. Indian Drugs, 2002;39: 422-425.

Manjula BS, Srinatha A, Sridhar BK. Evaluation of hydrophilic polymers and their combinations in formulation of sustained-release matrix tablets of water-soluble drug. India J PharmaEdu and Res, 2014; 48: 48-59. https://doi. org/10. 5530/ijper. 48. 3. 7

Marshall K. 1986. Compression and consolidation of powdered solids. In: Lachman L, Lieberman HA, Kanig JL, eds. The Theory and Practice of Industrial Pharmacy. Bombay: Varghese Publishing.

Mohammadi MS, Harnby N. Bulk density modelling as a means of typifying the microstructure and flow characteristics of cohesive powders. Powder Tech, 1997; 92: 1-8https://doi. org/10. 1016/S0032-5910(96)03254-8

Muhammad TA, Shoaib H, Yousuf RI, Jabeen S, Muhammad IN, Tariq S. Use of hydrophilic and hydrophobic polymers for the development of controlled release tizanidine matrix tablets. Braz J Pharm Sci, 2014; 50: 799-818. https://doi. org/10. 1590/S1984-82502014000400016

Odeku OA, Awe OO, Popoola B, Odeniyi MA and Itiola OA. Compression and mechanical properties of tablet formulations containing corn, sweet potato and cocoyam starches as binders. Pharm Technol, 2005; 29: 82-90.

Odeku OA, Itiola OA. Evaluation of the effect of khaya gum on the mechanicaland release properties of paracetamol tablets. Drug Dev and Ind Pharm, 2003; 29: 13-20. https://doi. org/10. 1081/DDC-120018205

Odeniyi MA, Atolagbe FM, Aina OO, Adetunji OA. Evaluation of mucoadhesive properties of native and modified starches of the root tubers of cocoyam (Xanthosomasagittifolium). Afr J Biomed Res, 2011; 14: 169-174.

Odeniyi MA, Onu RN, Adetunji OA. Evaluation of bioadhesive properties of natural and modified banana starches. East and Central Afr J Pharm Sci, 2011; 14: 34–42.

Patra CN, Pandit HK, SinghSP, DeviMV. Applicability and comparative evaluation of wet granulation and direct compression technology to Rauwolfia serpentine root powder: A technical note AAPS Pharm SciTech, 2008;9: 100-104. https://doi. org/10. 1208/s12249-007-9015-7

Pawar H, D'mello PM. Isolation of seed gum from Cassia tora and preliminary studies of its application as a binder for tablets. Indian Drugs, 2004;41: 465-468

Potu A, Veerareddy P, Jukanti R, Burra S. Formulation and evaluation of gum based matrix tablets of Lamivudine. Der Pharmacia Sinica, 2011; 2: 176-192

Prescot JK, Barnum RA. Powder flowability. Pharm Tech, 2000; 24: 60-84.

Raber M, Hoffman S, Junge K, Momberger H. Kuhn D. Analgesic efficacy and tolerability of tramadol 100 mg sustained release capsules in patients with moderate to severe chronic low back pain. Clin Drug Invest, 1999; 17: 415-423. https://doi. org/10. 2165/00044011-199917060-00001

Reddy MS, Archana S. Formulation and evaluation of sustained release tablets of repaglinide using hydrophilic natural and synthetic polymers. Int J PharmSci Res, 2018; 9: 2914-20.

Reus-Medina M, Lanz M, Kumar V, Leuenberger H. Comparative evaluation of the powder properties and compression behaviour of a new cellulose-based direct compression excipient and Avicel PH-102. J Pharm Pharmac, 2004; 56: 951-956. https://doi. org/10. 1211/0022357043987

Staniforth J. 2002. Powder flow. In: Aulton M, ed. Pharmaceutics, the science of dosage form design. Edinburgh:Churchill Livingstone 197.

Talukder M, Michoel MM, Rombaut AP, Kinget R. Comparative Study on xanthan gum and hydroxypropylmethylcellulose as matrices for controlled release. Drug delivery 1. Int J Pharm, 1996; 129: 231-241.

Varshosaz J, Tavakoli N, Eram SA. Use of natural gums and cellulose derivatives in production of sustained release metoprolol tablets. Drug Deliv, 2006; 13: 113-119. https://doi. org/10. 1080/10717540500313356

Varshosaz J, Tavakoli N, Kheirolahi F. Use of hydrophilic natural gums in formulation of sustained release matrix tablets of tramadol hydrochloride. AAPS Pharm Sci Tech, 2006; 7: 21-30. https://doi. org/10. 1208/pt070124

Wade A, Weller PJ. 1994. Handbook of Pharmaceutical Excipients. The Pharmaceutical Press: London 426-428.
